High-performance AC Servo Dve R5 Series
The fifth generation high-performance servo R5 series is based on the powerful R-AI algorithm and a new hardware solution. With Rtelligent rich experience in the development and application of servo for many years, the servo system with high performance, easy application and low cost has been created. Products in 3C, lithium, photovoltaic, logistics, semiconductor, medical, laser and other high-end automation equipment industry has a wide range of applications.
· Power range 0.5kw~2.3kw
· High dynamic response
· One-key self-tuning
· Rich IO interface
· STO security features
· Easy panel operation
-
High-Performance AC Servo Drive
RS series AC servo is a general servo product line developed by Rtelligent , covering the motor power range of 0.05 ~ 3.8kw. RS series supports ModBus communication and internal PLC function, and RSE series supports EtherCAT communication . RS series servo drive has a good hardware and software platform to ensure that it can be very suitable for fast and accurate position, speed, torque control applications.
• Matching motor power below 3.8kW
• High speed response bandwidth and shorter positioning time
• With 485 communication function
• With orthogonal pulse mode
• With frequency division output function
-
RSE
RS series AC servo is a general servo product line developed by Rtelligent, covering the motor power range of 0.05~3.8kw. RS series supports ModBus communication and internal PLC function, and RSE series supports EtherCAT communication. RS series servo drive has a good hardware and software platform to ensure that it can be very suitable for fast and accurate position, speed, torque control applications.
• Better hardware design and higher reliability
• Matching motor power below 3.8kW
• Complies with CiA402 specifications
• Support CSP/CSW/CST/HM/PP/PV control mode
• The minimum synchronization period in CSP mode: 200bus
-
Cost-effective AC Servo Drive RS-CS/CR
RS series AC servo is a general servo product line developed by Rtelligent, covering the motor power range of 0.05 ~ 3.8kw. RS series supports ModBus communication and internal PLC function, and RSE series supports EtherCAT communication. RS series servo drive has a good hardware and software platform to ensure that it can be very suitable for fast and accurate position, speed, torque control applications.
• High stability, Easy and convenient debugging
• Type-c: Standard USB, Type-C Debug interface
• RS-485: with standard USB communication interface
• New front interface to optimize wiring layout
• 20Pin press-type control signal terminal without soldering wire, easy and fast operation
-
5-Pole Pairs High Performanc AC Servo Motor
Rtelligent RSN series AC servo motors, based on Smd optimized magnetic circuit design, use high magnetic density stator and rotor materials, and have high energy efficiency.
Multiple types of encoders are available, including optical, magnetic, and multi-turn absolute encoder.
• RSNA60/80 motors have more compact size, saving installation cost.
• Permanent magnet brake is optional, moves flexible, suit for Z -axis applications.
• Brake optional or Bake for option
• Multi type of encoder available
• IP65/IP66 Optional or IP65/66 for option
-
Introduction to the AC servo motor of the RSNA
Rtelligent RSN series AC servo motors, based on Smd optimized magnetic circuit design, use high magnetic density stator and rotor materials, and have high energy efficiency.
Multiple types of encoders are available, including optical, magnetic, and multi-turn absolute encoder.
RSNA60/80 motors have more compact size, saving installation cost.
Permanent magnet brake is optional, moves flexible, suit for Z -axis applications.
Brake optional or Bake for option
Multi type of encoder available
IP65/IP66 Optional or IP65/66 for option
