Rtelligent D5V Series DC servo drive is a compact drive which has been developed to meet a more demanding global market with better functionalities, reliability and cost efficiency. The product adopts a new algorithm and hardware platform, supports RS485, CANopen, EtherCAT communication, supports internal PLC mode, and has seven basic control modes (position control, speed control, torque control, etc. The power range of this series of products is 0.1 ~ 1.5KW, suitable for a variety of low voltage and high current servo applications.
• Power range up to 1.5kw
• High speed response frequency,shorter
• Comply with CiA402 standard
• Support CSP/CSV/CST/PP/PV/PT/HM mode
• Outfitted for high current
• Mulitple communication mode
• Suitable for DC power input applications
